Description
Our 20-foot edible oil tank container is specifically designed for the safe transportation of food-grade oils. With a capacity of 21-26cubic meters, it provides ample space to store and transport a variety of edible oils, including vegetable oil, olive oil, and sunflower oil. Constructed from high-quality, food-grade carbon steel, this tank ensures compliance with strict safety and hygiene standards.
Specification
|
M.G.W.
|
36,000 kg
|
|
Tare (est.)
|
3,250 kg +/- 3%
|
|
Max Payload
|
32,750 kg
|
|
Working Pressure
|
4 Bar
|
|
Test Pressure
|
6 Bar
|
|
Design Temp
|
-40ºC to +130ºC
|
|
Vessel Material
|
SANS 50028-7 WNr 1.4402/14404 (C<0.03%), equivalent to 316L
|
|
Shell: Cold Rolled 2B finish
|
|
|
Ends: Hot rolled or Cold Rolled, polished internally to 1.2 Micron CLA
|
|
|
Shell Thickness
|
4.4 nominal
|
|
Ends Thickness(B.F)
|
4.5 mm nominal
|
|
4.6 mm nominal
|
|
|
Corrosion Allowance
|
0.2mm
|
|
Frame Material
|
GB/T 1591-Q345D or SPA-H (or equivalent)
|
|
Frame to Shell
|
316 stainless steel
|
|
Corner castings
|
ISO 1161 – 8 off
|
|
Vessel Design Code
|
ASME VIII Div 1 where applicable
|
The stainless steel storage tanks above ground suitable for field as edible oil, juice, beverage,
medicine chemical or bio-engineering project,etc. We manufacture tanks for the petroleum,
chemical, and water storage . Our product includes carbon steel, stainless steel, and fiberglass
storage oil tanks. We offer a complete range of above ground oil tanks including: gasoline
and diesel tank systems, potable water tanks, and a variety of customize oil storage
tanks for your specific requirement.
